Wood chipper RM 160 TK (angular)
Chippers RM 160 TK (angular)
Wood shredder RM 160 TC - is designed for shredding wood: siding, slats, crooks, tree branches into technological chips.
It is used in logging companies, sawmills, woodworking companies, pulp and paper mills, utilities and private companies. Due to the fact that the machine is equipped with a frame with a trailer, it can be used together with a trailer, which allows you to transport the crushed material with the machine to the destination and use only one tractor.
Scope of application
Shredding wood- Shredding wood
- Chopping branches
- Other wood waste
Advantages
- Performance до 8 m³/h
- Working body (rotor) - knife type
- Crushes up to 160mm
- Chip ejection height 4 m
- Autonomous hydraulic system
- Hydraulic wood feed
Specifications
| Power consumption, h.p. |
from 80 h.p. |
| Disk rotation frequency, rpm |
1000 |
| Wood feeding speed, m/s. |
from 0,8м |
| Max. productivity, m³/hour. |
8 |
| Raw material ejection height, m. |
4,0 |
| Length, mm. |
1600 |
| Height with pipe, mm. |
3500 |
| Height without pipe, mm. |
1750 |
| Width, mm. |
1600 |
| Weight, kg. |
950 |
